Ford Raptor R: 4X4 VXL 1/10 Scale 4X4 Brushless Replica Truck

Awesome RC Cars

Model Name:	Ford Raptor R 4X4 VXL: 1/10 Scale 4X4 Brushless Replica Truck
Model Type:	Short Course Trucks
Model Speed:	60+ mph with optional gearing and 3s LiPo battery (items sold separately)
Model Skill Level:	1
Scale:	1/10
Weight:	6.05 pounds (2.74 kg)
Length:	24.98 inches (637 mm)
Width:	11.63 inches (289 mm)
Front Track:	11.63 inches (289 mm)
Rear Track:	11.63 inches (289 mm)

Height:	8.91 inches (226 mm)
Wheelbase:	15.11 inches (384 mm)
Center Ground Clearance:	2.05 inches (52 mm)
Drive System:	Shaft-driven 4WD
Drivetrain:	Shaft-driven 4WD
Differential Type:	Hardened steel bevel, sealed, limited slip
Gear Pitch:	32 pitch
Servo(s):	2075 high-torque waterproof
Radio System:	TQi™ 2.4 GHz 2-channel radio
Battery Compartment Specs:	165 mm X 50 mm X 23/26 mm

Motor Name:	Velineon® 3500
Motor Type:	Sensorless brushless
Motor Weight:	9.24 ounces (262 g)
Motor Length:	3.03 inches (77 mm) overall length, 2.2 inches (56 mm) can length
Motor Diameter:	1.41 inches (36 mm)
Motor Shaft Size:	3 mm
Motor Connector Type:	3.5 mm bullet
